Battery
Isolation Switch
LF-A272996A3G0
- Double Pole Double Throw Switch
- 3 Position On-Off-On
- Contact resistance : 20mΩ max. (initial)
- Insulation resistance : 100mΩ min. (at 500V DC)
- Dielectric strength : 1500V AC 50/60 Hz for 1 min.
- Service life : Mechanically-100000 operations min.
- Electrically-30000 operations min.
- Rating : 20Amps @ 12Volts DC / 15Amps @ 24Volts DC
